Euro Air - Fabric Ducts

FBS Panels are made of flame retardant textile materials with an impermeable panel top so that air is distributed above the room and not above the ceiling. The panel top allows for directional control of air into the room. The entire visible surface is used actively for air distribution. Which generates low inlet air velocities and thus draft-free air distribution and low pressure loss.

The FBS panel design is a great advantage for solutions involving cooling or isothermal air distribution. The panels are available in two types: Type 1, a pure low impulse solution and type 2, a solution with DFC baffles allowing for directional air distribution.

• Draught free air distribution
• Fully integrated in suspended ceiling
• Low pressure loss
• Low sound pressure level (as low as <20 dB(A))
• Low weight
• Easy installation and maintenance
• Supplied as single panels or combined into a set of panels
• Tools not necessary
• Available in standard and special colours

DFC-HT Polyester material made of High Tenacity Filament fibres and woven by the weaving mill of Euro Air. The DFC-HT materials are woven in a plain weave that combined with the heavy-duty ”High Tenacity Fibres” creates a strong, even and wear-resistant textile surface.

The DFC-HT material has been approved for clean room applications, ISO class 4 acc. to ISO
14644-1.

• Tested to EN 13501
• Patented DFC Technology (Directional Flow Control)
• Anti-Condensation Fabric Design
• High Tensile Strength at >1700 N/50mm
• High Resistance to Tearing 130 N
• F7 Filter Class
• 0.5mm Thickness at 277 g/m2 / 0.4mm Thickness at 270 g/m2
• Low water absorption rate

DFC-HT Polyester material made of High Tenacity Filament fibres and woven by the weaving mill of Euro Air. The DFC-HT materials are woven in a plain weave that combined with the heavy-duty ”High Tenacity Fibres” creates a strong, even and wear-resistant textile surface.

The DFC-HT material has been approved for clean room applications, ISO class 4 acc. to ISO 14644-1.

• Tested to EN 13501
• Patented DFC Technology (Directional Flow Control)
• Anti-Condensation Fabric Design
• High Tensile Strength at >2200 N/50mm
• High Resistance to Tearing 200 N
• F7 Filter Class
• 0.4mm Thickness at 230 g/m2
• Low water absorption rate

TREVIRA CS polyester material is made of TREVIRA CS fibres and woven by the weaving mill of Euro Air. The TREVIRA CS materials are woven in a twill weave that combined with the heavy and twisted staple fibres ensure the largest possible textile surface and by that longer washing intervals.

• Tested to EN 13501
• Patented DFC Technology (Directional Flow Control)
• Anti-Condensation Fabric Design
• High Tensile Strength at >2200 N/50mm
• High Resistance to Tearing 200 N
• F7 Filter Class
• 0.4mm Thickness at 230 g/m2
• Low water absorption rate

TREVIRA CS polyester material is made of TREVIRA CS fibres and woven by the weaving mill of Euro Air. The TREVIRA CS materials are woven in a twill weave that combined with the heavy and twisted staple fibres ensure the largest possible textile surface and by that longer washing intervals.

• Tested to EN 13501
• Patented DFC Technology (Directional Flow Control)
• Anti-Condensation Fabric Design
• High Tensile Strength at >2800 N/50mm
• High Resistance to Tearing 167 N / 178 N
• F6 / F5 Filter Class
• 0.6mm Thickness at 300 g/m2 / 0.6mm Thickness at 290 g/m2
• Low water absorption rate

TREVIRA CS polyester material is made of TREVIRA CS fibres and woven by the weaving mill of Euro Air. The TREVIRA CS materials are woven in a twill weave that combined with the heavy and twisted staple fibres ensure the largest possible textile surface and by that longer washing intervals.

• Tested to EN 13501
• Patented DFC Technology (Directional Flow Control)
• Anti-Condensation Fabric Design
• High Tensile Strength at >2900 N/50mm / >2700 N/50mm
• High Resistance to Tearing 166 N / 144 N
• F5 / G4 Filter Class
• 0.6mm Thickness at 280 g/m2 / 0.6mm Thickness at 340 g/m2
• Low water absorption rate
